Shenzhen Jaguar Automation Equipment Co., Ltd
6 Years
| Ask Lasest Price | |
| Brand Name : | Jaguar |
| Model Number : | INC-350 |
| Certification : | CE ISO9001 |
| Price : | Negotiation |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 2 + Set + per Day |
| Delivery Time : | 5-8 days |
PCB Automatic Wave Soldering Loader Unloader INC-300 Intelligent Wave Soldering Infeed Conveyor DIP
| Model | INC-350 |
| Demensions(L×W×H) | 1000*700*750(mm) |
| PCB width | 0-350(mm) |
| PCB direction | L-R |
| Conveyor speed | 0-2000(mm)/Min |
| Motor | 1P AC220V 50/60HZ 15W |
| Power supply | 1P AC220V 50/60HZ |
| Conveyor Height | 750±20mm |
| Belt Material | ESD Belt |
| Conveyor length | 1000(mm) |
| Weight | Approx.45Kg |
Product features:
1. It is used to feed PCB’s or pallets into wave soldering machine at 6-7°.
2. Conveyor width and angle can be adjusted by hand crank.
3. Special belt and track, transmission smooth, and work stable and reliable.
INC-350 Automatic Wave Solder PCB Loader can match all Wave Soldering Machines in DIP line, and acted as an important part to improve production efficiency, which maximum PCB width reach to 350mm, can meet the most size of PCB, and conveyor speed can arrive to 2000mm/min, customer can select their speed according to speed of total production line, so very friendly for users.
Wave Solder Loader In Customer Factory
Products Display
DIP Line
|
|
